69350-2V-110
DUAL VOLTAGE TWIN TURBO REFRIGERANT RECOVERY SYSTEM

Product Description

THIS ITEM IS NO LONGER AVAILABLE

This unit offers all the same functions and features as the 69300. In addition it has an oil separation module, filter dryer and sight glass.

FEATURES & BENEFITS:

• Revolutionary double piston oil-less compressor
• Safety high pressure switch
• Simple internal structure for field service
• Largest volume recovery rate in market
• For use with all refrigerants including R410A
• Injection molded high density polyethylene case for maximum durability
• Front cover has bumper guards built in to reduce damage to the control knobs

SPECIFICATIONS:

• Dual Voltage 110/220 V – 50/60 Hz – 110 V Cable
• 1/2 HP Oil Less Compressor
• Recovery Rate:
  • R134a
  • Direct vapor up to .537 lb/min
  • Direct liquid up to 4.72 lb/min
  • Push pull up to 11.68 lb/min
  • R22
  • Direct vapor up to .63 lb/min
  • Direct liquid up to 7.56 lb/min
  • Push pull up to 18.3 lb/min
  • R410A
  • Direct vapor up to .70 lb/min
  • Direct liquid up to 7.7 lb/min
  • Push pull up to 20.2 lb/min
• Operating Temperature: 32 to 122°F
• Weight: 28.3 lbs
• Dimensions: 18” (l) x 10” (w) x 14” (h)
• Case Material is HDPE (High Density Polyethylene)
• Compatible Refrigerants: All CFC, HCFC, and HFC’s

Also Available:
69350-2V-220: Dual Voltage 110/220 V – 50/60 Hz – 220 V Cable (Schuko)
69350-2V-UK: Dual Voltage 110/220 V – 50/60 Hz – UK Cable
69500-DR: Replacement Filter Dryer
